Brake Drum Forges are design to hold solid fuels to heat metal for the purpose of hot work forging.[1]
Status
Section titled “Status”We are currently in the design and acquisition phase of the project. So far we’ve acquired a cast iron brake drum. It’s a GM part for older heavy duty trucks.
Things We Need
Section titled “Things We Need”- Clay (possibly)
- Welder
- Steel Plate
- Iron Pipe
- Steel Sheet Metal
- Sheet Metal Shears
- Blower
- Misc Hand Tools
- Someone with Sheet Metal Experience
- There may be some other items needed, but from what I can see this should be most of it.
Active Members
Section titled “Active Members”- Stuart
- Build a Forge for Forge Welding
- Take Pictures of the Process
- Stay within a budget of $300
Design
Section titled “Design”
Coal Forge Diagram
- Currently we’re working on the design of a Tuyere, Blower, Fire Pot, Forge Table and a Stand/Legs.
Tuyere
Section titled “Tuyere”
Front View of Tuyere
- We will take a 4” cast iron pipe and flare it to fit the Fire Pot.
- We will take triangular piece of metal and attach it to a 3/8” steel rod with a 90deg bend to form a clinker breaker.
Fire Pot
Section titled “Fire Pot”- We are using a Cast Iron Brake Drum for the Fire Pot.
Blower
Section titled “Blower”- Need a squirrel cage type blower
Forge Table
Section titled “Forge Table”- TBD
Stand/Legs
Section titled “Stand/Legs”- TBD
